DESCRIPTION

Basic Info

Model NO.	Alumina Ceramic Lining
Origin	Shandong Zibo
HS Code	6909120000
Production Capacity	50000 Pieces a Year

Product Description

Basic Info.

Name	Long(L)mm	Outside diameter(R)mm	Internal diameter(r)mm	Notes
Alumina Ceramic Tube	≤500	30-450	30-450	Tolerance of each dimension±1%

Support for product customization



Parameters of heat resistant Al2O3 ceramic

Product Name	Industrial Ceramic
Material	92%/95%/96%/99% /99.6%Alumina
Color	Ivory
Size	different types/customization
Process	Tape casting
Payment	T/T,Western Union,Online payment by credit card are available
Application	It is widely used in MOS tube/Miniature radiator etc
Thransport	Air transport: 5-10 days; Ocean shipping: About one month.
Delivery Time	1.Stock:delivery within 3-5 days after receiving your payment. 2. OEM/ODM:The normal Lead time is 15-45 days, which depends on your quantiy.

Points to note for transport and installationMatters needing attention for transportation and installation of ceramic pipe1. The ceramic composite pipe has high hardness and good toughness, but it should be put gently in the process of transportation and installation to avoid serious collision, especially to avoid direct contact with metal instruments or impact on the ceramic layer on the end surface.2. The qijing bending pipe is installed with directivity. When the bending pipe is installed, the direction indicated by the arrow on the surface of the bending pipe should be consistent with the flow direction of the conveying medium.3. When installing the pipe, the pipe should be aligned with the center line and level should be adjusted to make sure that both ends meet accurately.The displacement of both ends should be controlled within 1.0mm.4. When the flexible pipe joint is used to connect and install the pipe, the inserted lengths of both ends of the flexible pipe joint shall be adjusted symmetrically.Since the thermal expansion coefficient of the composite pipe is about 1/3 of that of steel, the expansion clearance can be reduced by 3-5mm.5. When using flange connection, the flange end shall be flush with the end of the composite pipe.6. Due to the excellent welding performance of the composite pipe, the pipe connection can be conducted by welding. However, when welding, 45o-60o "V" type slope Angle is 2-4mm and gap is 0.8-1.2mm.



FAQ
01.How to buy your products? A: You can provide us yourtechnical parameters.(connect us for more details).02. How to pay? A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.03. What is the delivery time? A: It depends on order quantities. Generally speaking, the delivery time will be within 4 to 6 weeks.04. How to install after the equipment arriving destination? A: We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
